14 💻 Binary Logistic Regression

14.1 Objectives

At the end of the chapter, the readers will be

to understand the concept of simple and multiple binary logistic regression 14
to perform simple binary logistic regression 14
to perform multiple binary logistic regression 14
to perform model assessment of binary logistic regression
to present and interpret results from binary logsitic regression

14.2 Background

The logistic model (or logit model) is used to model the probability of a certain class or event existing such as pass or fail, win or lose, alive or dead or healthy or sick. More specifically, binary logistic regression is used to model the relationship between a covariate or a set of covariates and an outcome variables which is a binary variable.

A binary variable is a categorical outcome has two categories or levels. In medical and health research, binary outcome variable is very common. Some example where the outcome is binary include:

survival status when the status of cancer patients at the end of treatment are coded as either alive or dead
relapse status when the status of a patient is coded as either relapse or not relapse
satisfaction level when patients who come to clinics are asked if they are satisfied or not satisfied with the service
glucose control when patients were categorized as either good control or poor control based on Hba1c

In a binary logistic regression model, the dependent variable has two levels (categorical). When the outcome variable has more than two levels or categories, the analysis are modeled by multinomial logistic regression and, if the multiple categories are ordered, by ordinal logistic regression (for example the proportional odds ordinal logistic model).

14.3 Further readings

There are a number of good references to help readers understand binary logistic regression better. The references that we list below also contains workflow that will be useful for readers when modelling logistic regression.

We highly recommend readers to read

the Applied Logistic Regression book²¹
the Logistic Regression: Self Learning Text²²
the workflow from A Handbook of Statistical Analyses Using R²³

14.4 Dataset

We will use a dataset named stroke.dta which in STATA format. These data come from a study of hospitalized stroke patients. They original dataset contain 12 variables but our main variables of interest are:

status : Status of patient during hospitalization (alive or dead)
gcs : Glasgow Coma Scale on admission (range from 3 to 15)
stroke_type : IS (Ischaemic Stroke) or HS (Haemorrhagic Stroke)
sex : female or male
dm : History of Diabetes (yes or no)
sbp : Systolic Blood Pressure (mmHg)
age : age of patient on admission

The outcome variable is variable status. It is labelled as either dead or alive which is the outcome of each patient during hospitalization.

14.5 logit and logistic models

The simple binary logit and logistic models refer to a a model with only one covariate (also known as independent variable). For example, if the covariate is gcs (Glasgow Coma Scale), the simple logit model is written as:

$\hat{g} (x) = l n [\frac{\hat{π} (x)}{1 - \hat{π} (x)}]$

where $\hat{g} (x)$ is the log odds for death for a given value of gcs. And the odds for death for a given value of GCS is written as $= {\hat{β}}_{0} + {\hat{β}}_{1} (g c s)$

And the simple logistic model is also written as:

$\hat{π} (x) = \frac{e x p^{{\hat{β}}_{0} + {\hat{β}}_{1} g c s}}{1 + e x p^{{\hat{β}}_{0} + {\hat{β}}_{1} g c s}}$ The $π (x) = E (Y | x)$ represents the conditional mean of $Y$ given $x$ when the logistic distribution is used. This is also simply known as the predicted probability of death for given value of gcs.

If we have decided (based on our clinical expertise and literature review) that a model that could explain death consists of gcs, stroke type, sex, dm, age and sbp, then the logit model can be expanded to:

$\hat{g} (x) = {\hat{β}}_{0} + {\hat{β}}_{1} (g c s) + {\hat{β}}_{2} (s t r o k e t y p e) + {\hat{β}}_{3} (s e x) + {\hat{β}}_{4} (d m) + {\hat{β}}_{5} (s b p) + {\hat{β}}_{6} (a g e)$ This is the odds for death given certain value of gcs, sbp and age and certain categories of stroke stype, sex and diabetes. While the probability of deaths is

$\hat{π} (x) = \frac{e x p^{{\hat{β}}_{0} + {\hat{β}}_{1} (g c s) + {\hat{β}}_{2} (s t r o k e t y p e) + {\hat{β}}_{3} (s e x) + {\hat{β}}_{4} (d m) + {\hat{β}}_{5} (s b p) + {\hat{β}}_{6} (a g e)})}{1 + e x p^{{\hat{β}}_{0} + {\hat{β}}_{1} (g c s) + {\hat{β}}_{2} (s t r o k e t y p e) + {\hat{β}}_{3} (s e x) + {\hat{β}}_{4} (d m) + {\hat{β}}_{5} (s b p) + {\hat{β}}_{6} (a g e)}}$

In many datasets, some of the independent variables are discrete, nominal scale variables such as race, sex, treatment group, and so forth. And because of that it is inappropriate to include them in the model as if they were interval scale variables. Though in many software, they are represented by numbers, but these numbers are used merely identifiers.

In this situation, we will use a method called design variables (or dummy variables). Suppose, for example, assuming that one of the independent variables is obesity type, which is now coded as “Class 1”, “Class 2” and “Class 3”. In this case, there are 3 levels or categories, hence two design variables ( $D - 1$ ) are necessary, let’s say D1 and D2. One possible coding strategy is that when the patient is in “Class 1” then the two design variables, for D1 and D2 would both be set equal to zero. In this example, “Class 1” is the reference category. When the patient is in “Class 2”, then D1 is set as 1 and D2 as 0; when the patient is in “Class 3”, the we will set D1 as 0 and D2 and 1. All these coding assignment can be done automatically in the software. But to interpret, we must know which category is the reference.

14.6 Prepare environment for analysis

14.6.1 Creating a RStudio project

Start a new analysis task by creating a new RStudio project. To do this,

Go to File
Click New Project
Choose New Directory or Existing Directory.

This directory points to the folder that usually contains the dataset to be analyzed. This is called as the working directory. Make sure there is a folder named as data in the folder. If there is not, create one. Make sure the dataset stroke.dta is inside the data folder in the working directory.

14.6.2 Loading libraries

Next, we will load the necessary packages. We will use 5 packages

the built in stat package - to run Generalized Linear Model. This is already loaded by default.
haven - to read SPSS, STATA and SAS dataset
tidyverse - to perform data transformation
gtsummary - to provide nice results in a table
broom - to tidy up the results
LogisticDx - to do model assessment
here - to ensure proper directory

To load these packages, we will use the function library():

library(haven)
library(tidyverse)
#> ── Attaching packages ─────────────────── tidyverse 1.3.2 ──
#> ✔ ggplot2 3.3.6     ✔ purrr   1.0.1
#> ✔ tibble  3.1.8     ✔ stringr 1.5.0
#> ✔ tidyr   1.3.0     ✔ forcats 1.0.0
#> ✔ readr   2.1.2
#> ── Conflicts ────────────────────── tidyverse_conflicts() ──
#> ✖ lubridate::as.difftime() masks base::as.difftime()
#> ✖ lubridate::date()        masks base::date()
#> ✖ dplyr::filter()          masks stats::filter()
#> ✖ kableExtra::group_rows() masks dplyr::group_rows()
#> ✖ lubridate::intersect()   masks base::intersect()
#> ✖ dplyr::lag()             masks stats::lag()
#> ✖ lubridate::setdiff()     masks base::setdiff()
#> ✖ lubridate::union()       masks base::union()
library(gtsummary)
library(broom)
library(LogisticDx)
library(here)
#> here() starts at /Users/niccolo/Desktop/r_projects/sbd_22-23

14.7 Read data

WE will read data in the working directory into our R environment. Remember the dataset is in the STATA format.

fatal <- read_dta(here('data','stroke.dta'))

Take a peek at data. Check

variable names
variable types

glimpse(fatal)
#> Rows: 226
#> Columns: 7
#> $ sex         <dbl+lbl> 1, 1, 1, 2, 1, 2, 2, 1, 2, 2, 1, 2…
#> $ status      <dbl+lbl> 1, 1, 1, 1, 1, 1, 2, 1, 1, 2, 1, 1…
#> $ gcs         <dbl> 13, 15, 15, 15, 15, 15, 13, 15, 15, 10…
#> $ sbp         <dbl> 143, 150, 152, 215, 162, 169, 178, 180…
#> $ dm          <dbl+lbl> 0, 0, 0, 1, 1, 1, 1, 0, 1, 1, 0, 1…
#> $ age         <dbl> 50, 58, 64, 50, 65, 78, 66, 72, 61, 64…
#> $ stroke_type <dbl+lbl> 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0…

14.8 Explore data

Variables sex, status, dm and stroke type are labelled variable. This means eventhough they are coded as numbers but the numbers represent the groups or categories or levels of the variables. Basically, they are categorical variables.

We will transform all of them to factor variables. We can quickly do this using the function across(). Below, we will transform all labelled variables to factor variables:

fatal <-
  fatal %>%
  mutate(across(where(is.labelled), as_factor))

Now, we can look at the summary statistics

fatal %>%
  tbl_summary() %>%
  as_hux_table()

Table 14.1:
Characteristic	N = 226
sex
male	97 (43%)
female	129 (57%)
alive or dead
alive	171 (76%)
dead	55 (24%)
earliest Glasgow Coma Scale	15.0 (10.0, 15.0)
earliest systolic BP (mmHg)	161 (143, 187)
diabetes (yes or no)	138 (61%)
age in years	61 (52, 69)
Ischaemic Stroke or Haemorrhagic
Ischaemic Stroke	149 (66%)
Haemorrhagic	77 (34%)
n (%); Median (IQR)

or to get summary statistics for each status category:

fatal %>%
  tbl_summary(by = status) %>%
  as_hux_table()

Table 14.2:
Characteristic	alive, N = 171	dead, N = 55
sex
male	81 (47%)	16 (29%)
female	90 (53%)	39 (71%)
earliest Glasgow Coma Scale	15.0 (14.0, 15.0)	8.0 (5.0, 11.0)
earliest systolic BP (mmHg)	160 (143, 186)	162 (140, 199)
diabetes (yes or no)	100 (58%)	38 (69%)
age in years	61 (53, 68)	62 (50, 73)
Ischaemic Stroke or Haemorrhagic
Ischaemic Stroke	132 (77%)	17 (31%)
Haemorrhagic	39 (23%)	38 (69%)
n (%); Median (IQR)

14.9 Estimate the regression parameters

We now can perform binary logistic regression to estimate the regression parameters ${\hat{β}}_{s}$ or the log odds. Usually, we can do this in two steps:

The simple binary logistic regression or the univariable logistic regression. In this analysis, there is only one independent variable or covariate in the model. This is also known as the crude or unadjusted analysis.
The multiple binary logistic regression or the multivariable logistic regression. Here, we expand our model and include two or more independent variables (covariates). This is a adjusted model and we can obtain the estimate of a particular covariate independent of the other covariates in the model.

14.10 Simple binary logistic regression

The simple binary logistic regression has a dependent variable and only one independent (covariate) variable. in our dataset, for example, we can have

status as the dependent variable.
gcs as the independent variable.

The independent variable can be a numerical or a categorical variable. To estimate the log odds (the regression parameters, $β$ ) for the covariate Glasgow Coma Scale (GCS), we can write the logit model as:

$l o g \frac{p (s t a t u s = d e a d)}{1 - p (s t a t u s = d e a d)} = {\hat{β}}_{0} + {\hat{β}}_{1} (g c s)$

In R, we use the glm() function to estimate the regression parameters and other parameters of interest. Let’s run the model with gcs as the covariate and name the model as fatal_glm_1

fatal_glm_1 <-
  glm(status ~ gcs,
      data = fatal,
      family = binomial(link = 'logit'))

To get the summarized result of the model, we will use the summary() function:

summary(fatal_glm_1)
#>
#> Call:
#> glm(formula = status ~ gcs, family = binomial(link = "logit"),
#>     data = fatal)
#>
#> Deviance Residuals:
#>     Min       1Q   Median       3Q      Max
#> -2.1179  -0.3921  -0.3921  -0.3921   2.2820
#>
#> Coefficients:
#>             Estimate Std. Error z value           Pr(>|z|)
#> (Intercept)  3.29479    0.60432   5.452 0.0000000497803390
#> gcs         -0.38811    0.05213  -7.446 0.0000000000000964
#>
#> (Intercept) ***
#> gcs         ***
#> ---
#> Signif. codes:
#> 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
#>
#> (Dispersion parameter for binomial family taken to be 1)
#>
#>     Null deviance: 250.83  on 225  degrees of freedom
#> Residual deviance: 170.92  on 224  degrees of freedom
#> AIC: 174.92
#>
#> Number of Fisher Scoring iterations: 5

To get the model summary in a data frame format, so we can edit more easily, we can use the tidy() function from the broom package. The package also contains other functions to provide other parameters useful for us later.

The function conf.int() will provide the confidence intervals (CI). The default is set at the $95$ level:

tidy(fatal_glm_1, conf.int = TRUE)
#> # A tibble: 2 × 7
#>   term      estim…¹ std.e…² stati…³  p.value conf.…⁴ conf.…⁵
#>   <chr>       <dbl>   <dbl>   <dbl>    <dbl>   <dbl>   <dbl>
#> 1 (Interce…   3.29   0.604     5.45 4.98e- 8   2.17    4.55
#> 2 gcs        -0.388  0.0521   -7.45 9.64e-14  -0.497  -0.292
#> # … with abbreviated variable names ¹estimate, ²std.error,
#> #   ³statistic, ⁴conf.low, ⁵conf.high

The estimates here are the log odds for death for a given value of gcs. In this example, each unit increase in gcs, the crude or unadjusted log odds for death due to stroke change by a factor $- 0.388$ with $95$ CI ranges from $- 0.497 a n d - 0.292$ .

Now, let’s use another covariate, stroke_type. Stroke type has 2 levels or categories; Haemorrhagic Stroke (HS) and Ischaemic Stroke (IS). HS is known to cause higher risk for deaths in stroke. We will model stroke type (stroke_type), name the model as fatal_glm_2 and show the result using tidy()

fatal_glm_2 <-
  glm(status ~ stroke_type,
      data = fatal,
      family = binomial(link = 'logit'))
tidy(fatal_glm_2, conf.int = TRUE)
#> # A tibble: 2 × 7
#>   term      estim…¹ std.e…² stati…³  p.value conf.…⁴ conf.…⁵
#>   <chr>       <dbl>   <dbl>   <dbl>    <dbl>   <dbl>   <dbl>
#> 1 (Interce…   -2.05   0.258   -7.95 1.80e-15   -2.59   -1.57
#> 2 stroke_t…    2.02   0.344    5.88 4.05e- 9    1.36    2.72
#> # … with abbreviated variable names ¹estimate, ²std.error,
#> #   ³statistic, ⁴conf.low, ⁵conf.high

It seems that patients with Haemorrhagic Stroke (HS) had higher log odds for death during admission - by a factor $2.02$ - than patients with Ischaemic Stroke (IS).

14.11 Multiple binary logistic regression

The is strong motivation to include other covariates in the model. This is because

It is unlikely that only one variable (gcs or stroke type) that is related with stroke. For example, cardiovascular disease has many factors that affect the outcome. So, it makes more sense to consider adding other seemingly important independent variable in the model.
by adding more covariates in the model, we can estimate the adjusted log odds. These are the log odds of a particular covariate independent of other covariates.
we can add other covariate to adjust for the confounding effects
interaction (the product of two covariates) can also be estimated

To add or not to add variables is a big subject on its own. Usually it is governed by clinical experience, subject matter experts and some preliminary analysis.

Let’s expand our model and include gcs, stroke type, sex, dm, sbp and age in the model. We will name this model as fatal_mv. To run this model and get the estimates in R:

fatal_mv1 <-
  glm(status ~ gcs + stroke_type + sex + dm + sbp + age,
      data = fatal,
      family = binomial(link = 'logit'))

summary(fatal_mv1)
#>
#> Call:
#> glm(formula = status ~ gcs + stroke_type + sex + dm + sbp + age,
#>     family = binomial(link = "logit"), data = fatal)
#>
#> Deviance Residuals:
#>     Min       1Q   Median       3Q      Max
#> -2.3715  -0.4687  -0.3280  -0.1921   2.5150
#>
#> Coefficients:
#>                           Estimate Std. Error z value
#> (Intercept)             -0.1588269  1.6174965  -0.098
#> gcs                     -0.3284640  0.0557574  -5.891
#> stroke_typeHaemorrhagic  1.2662764  0.4365882   2.900
#> sexfemale                0.4302901  0.4362742   0.986
#> dmyes                    0.4736670  0.4362309   1.086
#> sbp                      0.0008612  0.0060619   0.142
#> age                      0.0242321  0.0154010   1.573
#>                              Pr(>|z|)
#> (Intercept)                   0.92178
#> gcs                     0.00000000384 ***
#> stroke_typeHaemorrhagic       0.00373 **
#> sexfemale                     0.32399
#> dmyes                         0.27756
#> sbp                           0.88703
#> age                           0.11562
#> ---
#> Signif. codes:
#> 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
#>
#> (Dispersion parameter for binomial family taken to be 1)
#>
#>     Null deviance: 250.83  on 225  degrees of freedom
#> Residual deviance: 159.34  on 219  degrees of freedom
#> AIC: 173.34
#>
#> Number of Fisher Scoring iterations: 5

We could get a cleaner result in a data frame format (and you can edit in spreadsheet easily) by using tidy():

log_odds <- tidy(fatal_mv1,
                 conf.int = TRUE)
log_odds
#> # A tibble: 7 × 7
#>   term     estimate std.e…¹ stati…² p.value conf.low conf.…³
#>   <chr>       <dbl>   <dbl>   <dbl>   <dbl>    <dbl>   <dbl>
#> 1 (Interc… -1.59e-1 1.62    -0.0982 9.22e-1 -3.38     3.01
#> 2 gcs      -3.28e-1 0.0558  -5.89   3.84e-9 -0.444   -0.224
#> 3 stroke_…  1.27e+0 0.437    2.90   3.73e-3  0.411    2.13
#> 4 sexfema…  4.30e-1 0.436    0.986  3.24e-1 -0.420    1.30
#> 5 dmyes     4.74e-1 0.436    1.09   2.78e-1 -0.368    1.35
#> 6 sbp       8.61e-4 0.00606  0.142  8.87e-1 -0.0110   0.0129
#> 7 age       2.42e-2 0.0154   1.57   1.16e-1 -0.00520  0.0555
#> # … with abbreviated variable names ¹std.error, ²statistic,
#> #   ³conf.high

We could see in the multivariable model, that

with one unit increase in Glasgow Coma Scale (GCS), the log odds for death during hospitalization equals to $- 0.328$ , adjusting for other covariates
patients with HS has $1.266$ times the log odds for death as compared to patients with IS, adjusting for other covariates.
female patients have $0.430$ times the log odds for death as compared to male patients, adjusting for other covariates
patients with diabetes mellitus had $0.474$ times the log odds for deaths as compared to patients with no diabetes mellitus
With one mmHg increase in systolic blood pressure, the log odds for deaths change by a factor of $0.00086$ , when adjusting for other variables.
with an increase in one year of age, the log odds for deaths change by a factor of $0.024$ , when adjusting for other variables.

14.12 Convert the log odds to odds ratio

For lay person, it is difficult to interpret the log odds. It is easier to interpret using the odds ratio. To do this, we can use the argument exponentiate = TRUE in the tidy() function. However, we also know that the odds ratio can be easily calculate by $\exp^{β_{i}}$

odds_ratio <- tidy(fatal_mv1,
                   exponentiate = TRUE,
                   conf.int = TRUE)
odds_ratio
#> # A tibble: 7 × 7
#>   term       estim…¹ std.e…² stati…³ p.value conf.…⁴ conf.…⁵
#>   <chr>        <dbl>   <dbl>   <dbl>   <dbl>   <dbl>   <dbl>
#> 1 (Intercep…   0.853 1.62    -0.0982 9.22e-1  0.0341  20.3
#> 2 gcs          0.720 0.0558  -5.89   3.84e-9  0.641    0.799
#> 3 stroke_ty…   3.55  0.437    2.90   3.73e-3  1.51     8.45
#> 4 sexfemale    1.54  0.436    0.986  3.24e-1  0.657    3.69
#> 5 dmyes        1.61  0.436    1.09   2.78e-1  0.692    3.87
#> 6 sbp          1.00  0.00606  0.142  8.87e-1  0.989    1.01
#> 7 age          1.02  0.0154   1.57   1.16e-1  0.995    1.06
#> # … with abbreviated variable names ¹estimate, ²std.error,
#> #   ³statistic, ⁴conf.low, ⁵conf.high

14.13 Making inference

Let us combine the results from the log odds and the odds ratio and rename the table properly.

tab_logistic <- bind_cols(log_odds, odds_ratio)
#> New names:
#> • `term` -> `term...1`
#> • `estimate` -> `estimate...2`
#> • `std.error` -> `std.error...3`
#> • `statistic` -> `statistic...4`
#> • `p.value` -> `p.value...5`
#> • `conf.low` -> `conf.low...6`
#> • `conf.high` -> `conf.high...7`
#> • `term` -> `term...8`
#> • `estimate` -> `estimate...9`
#> • `std.error` -> `std.error...10`
#> • `statistic` -> `statistic...11`
#> • `p.value` -> `p.value...12`
#> • `conf.low` -> `conf.low...13`
#> • `conf.high` -> `conf.high...14`
tab_logistic %>%
  select(term...1, estimate...2, std.error...3,
         estimate...9, conf.low...13, conf.high...14 ,p.value...5) %>%
  rename(covariate = term...1,
         log_odds = estimate...2,
         SE = std.error...3,
         odds_ratio = estimate...9,
         lower_OR = conf.low...13,
         upper_OR = conf.high...14,
         p.val = p.value...5)
#> # A tibble: 7 × 7
#>   covariate log_odds      SE odds_…¹ lower…² upper…³   p.val
#>   <chr>        <dbl>   <dbl>   <dbl>   <dbl>   <dbl>   <dbl>
#> 1 (Interce… -1.59e-1 1.62      0.853  0.0341  20.3   9.22e-1
#> 2 gcs       -3.28e-1 0.0558    0.720  0.641    0.799 3.84e-9
#> 3 stroke_t…  1.27e+0 0.437     3.55   1.51     8.45  3.73e-3
#> 4 sexfemale  4.30e-1 0.436     1.54   0.657    3.69  3.24e-1
#> 5 dmyes      4.74e-1 0.436     1.61   0.692    3.87  2.78e-1
#> 6 sbp        8.61e-4 0.00606   1.00   0.989    1.01  8.87e-1
#> 7 age        2.42e-2 0.0154    1.02   0.995    1.06  1.16e-1
#> # … with abbreviated variable names ¹odds_ratio, ²lower_OR,
#> #   ³upper_OR

In the model, it means that:

if gcs increases by 1 unit (when stroke type is adjusted), the log odds for death changes by a factor $- 0.32$ or the odds for death changes by a factor $0.72$ (odds for death reduces for $28 %$ ). The the $95 % C I$ are between $21 %, 36 %$ , adjusting for other covariates.
patients with HS has $3.55 %$ times higher odds for stroke deaths - with $95 % C I : 17 %, 85 %$ - as compared to patients with HS, adjusting for other independent variables.
female patients have $53 %$ higher odds for death as compared to female patients ( $p = 0.154$ ), adjusting for other covariates
patients with diabetes mellitus had $60.6 %$ higher odds for deaths compared to patients with no diabetes mellitus though the p value is above $5 %$ ( $p = 0.642 %$ )
With one mmHg increase in systolic blood pressure, the odds for death change by a factor $1.00086$ , when adjusting for other variables. The p value is also larger than $5 %$ .
with an increase in one year of age, the odds for deaths increase by a factor of $1.025$ , when adjusting for other variables. However, the p value is $0.115$

14.14 Model comparison

It is not advisable to assess the important of variables based on their p-values or the Wald statistics. The better way is to use likelihood ratio to compare models and assess the importance of variables.

For example, is there any statistical difference between model 1 (fatal_mv) and model 2 (fatal_glm_1) if we set the level of significance at $5 %$ ?

anova( fatal_glm_1, fatal_mv1, test = 'Chisq')
#> Analysis of Deviance Table
#>
#> Model 1: status ~ gcs
#> Model 2: status ~ gcs + stroke_type + sex + dm + sbp + age
#>   Resid. Df Resid. Dev Df Deviance Pr(>Chi)
#> 1       224     170.92
#> 2       219     159.34  5   11.582  0.04098 *
#> ---
#> Signif. codes:
#> 0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1

Both models are different statistically (at $5 %$ level). Hence, we prefer to keep model fatal_mv1.

Now let’s be economical, and just keep gcs, stroke type and age in the model. And let’s name this model as fatal_mv2

fatal_mv2 <-
  glm(status ~ gcs + stroke_type + age,
      data = fatal,
      family = binomial(link = 'logit'))

And perform model comparison again

anova( fatal_mv1,
       fatal_mv2, test = 'Chisq')
#> Analysis of Deviance Table
#>
#> Model 1: status ~ gcs + stroke_type + sex + dm + sbp + age
#> Model 2: status ~ gcs + stroke_type + age
#>   Resid. Df Resid. Dev Df Deviance Pr(>Chi)
#> 1       219     159.34
#> 2       222     161.51 -3  -2.1743    0.537

The p-value is above the threshold of $5 %$ , so we can not reject the null hypothesis that say both models are not statistically different. So by obeying the Occam’s razor principle, we will choose a simpler model that is model fatal_mv2 for further exploration.

14.15 Adding an interaction term

Interaction effects occur when the effect of one variable depends on the value of another variable. Interaction effects are common in regression analysis, ANOVA, and designed experiments.

Interaction involves two risk factors (and their effect on one disease outcome). If the effect of one risk factor is the same within strata defined by the other, then there is NO interaction. When the effect of one risk factor is different within strata defined by the other, then there is an interaction (biological)

(Statistical) interaction can be measured based on the ways that risks are calculated (modeling). The presence of interaction based on measurements is called statistical interaction, and inherently it may not reflect the true biological interaction.

Let’s add an interaction between stroke type and diabetes:

fatal_mv2_ia <-
  glm(status ~ gcs + stroke_type + stroke_type:gcs + age,
      data = fatal,
      family = binomial(link = 'logit'))
tidy(fatal_mv2_ia)
#> # A tibble: 5 × 5
#>   term                       estim…¹ std.e…² stati…³ p.value
#>   <chr>                        <dbl>   <dbl>   <dbl>   <dbl>
#> 1 (Intercept)                 0.508   1.37     0.371 7.10e-1
#> 2 gcs                        -0.320   0.0800  -4.01  6.19e-5
#> 3 stroke_typeHaemorrhagic     1.61    1.30     1.24  2.17e-1
#> 4 age                         0.0236  0.0147   1.60  1.09e-1
#> 5 gcs:stroke_typeHaemorrhag… -0.0347  0.111   -0.312 7.55e-1
#> # … with abbreviated variable names ¹estimate, ²std.error,
#> #   ³statistic

$\hat{g} (x) = {\hat{β}}_{0} + {\hat{β}}_{1} (g c s) + {\hat{β}}_{2} (s t r o k e t y p e) + {\hat{β}}_{3} (a g e) + {\hat{β}}_{4} (g c s \times s t r o k e_{t} y p e)$

To decide if an interaction term should stay in the model, we suggest you to consider the biological and statistical significance. If you think the interaction justifies both reasons, then it is preferred you keep the interaction term in the model. For example, for our model:

the coefficient for the interaction term for stroke type and gcs is not significant at %5%$ level.
after getting further advice from the stroke experts, we believe that the effect of gcs on stroke death is not largely different between different stroke type

And because of both reasons, we have decided not to keep the interaction for gcs and stroke type in the model.

14.16 Prediction from binary logistic regression

We can use the broom::augment() function to calculate the

log odds
probability
residuals
hat values
Cooks distance
standardized residuals

14.16.1 Predict the log odds

To obtain the .fitted column (representing the estimated log odds for death) for each patient, we can run:

log_odds_mv2 <- augment(fatal_mv2)
log_odds_mv2 %>%
  slice(1:10)
#> # A tibble: 10 × 10
#>    status   gcs strok…¹   age .fitted .resid .std.…²    .hat
#>    <fct>  <dbl> <fct>   <dbl>   <dbl>  <dbl>   <dbl>   <dbl>
#>  1 alive     13 Ischae…    50   -2.49 -0.398  -0.400 0.00991
#>  2 alive     15 Ischae…    58   -2.98 -0.314  -0.315 0.00584
#>  3 alive     15 Ischae…    64   -2.84 -0.337  -0.338 0.00590
#>  4 alive     15 Ischae…    50   -3.17 -0.287  -0.288 0.00657
#>  5 alive     15 Ischae…    65   -2.82 -0.341  -0.342 0.00599
#>  6 alive     15 Ischae…    78   -2.51 -0.395  -0.397 0.00980
#>  7 dead      13 Ischae…    66   -2.12  2.11    2.12  0.00831
#>  8 alive     15 Ischae…    72   -2.65 -0.369  -0.370 0.00731
#>  9 alive     15 Ischae…    61   -2.91 -0.325  -0.326 0.00579
#> 10 dead      10 Ischae…    64   -1.15  1.69    1.70  0.0173
#> # … with 2 more variables: .sigma <dbl>, .cooksd <dbl>, and
#> #   abbreviated variable names ¹stroke_type, ².std.resid

The slice() gives the snapshot of the data. In this case, we choose the first 10 patients.

14.16.2 Predict the probabilities

To obtain the .fitted column (representing the estimated probabilities for death) for each patient, we can run:

prob_mv2 <-
  augment(fatal_mv2,
          type.predict = "response")
prob_mv2 %>%
  slice(1:10)
#> # A tibble: 10 × 10
#>    status   gcs strok…¹   age .fitted .resid .std.…²    .hat
#>    <fct>  <dbl> <fct>   <dbl>   <dbl>  <dbl>   <dbl>   <dbl>
#>  1 alive     13 Ischae…    50  0.0763 -0.398  -0.400 0.00991
#>  2 alive     15 Ischae…    58  0.0482 -0.314  -0.315 0.00584
#>  3 alive     15 Ischae…    64  0.0551 -0.337  -0.338 0.00590
#>  4 alive     15 Ischae…    50  0.0403 -0.287  -0.288 0.00657
#>  5 alive     15 Ischae…    65  0.0564 -0.341  -0.342 0.00599
#>  6 alive     15 Ischae…    78  0.0750 -0.395  -0.397 0.00980
#>  7 dead      13 Ischae…    66  0.107   2.11    2.12  0.00831
#>  8 alive     15 Ischae…    72  0.0658 -0.369  -0.370 0.00731
#>  9 alive     15 Ischae…    61  0.0516 -0.325  -0.326 0.00579
#> 10 dead      10 Ischae…    64  0.241   1.69    1.70  0.0173
#> # … with 2 more variables: .sigma <dbl>, .cooksd <dbl>, and
#> #   abbreviated variable names ¹stroke_type, ².std.resid

14.17 Model fitness

We will assess the overall model fitness by checking the

the area under the curve
the Hosmer-Lemeshow test
the modidied Hosmer-Lemeshow test
the Oseo Rojek test

The p-values of bigger than 0.05 indicates that there is no significant difference between the observed data and the predicted data (from our model). That supports the good fit of the model.

fit_m <- gof(fatal_mv2,
             g = 8)
#> Setting levels: control = 0, case = 1
#> Setting direction: controls < cases

The area under the curve is $87.2 %$ . The values of above 80 are considered to have good discriminating effect.

fit_m$gof
#>          test  stat       val df      pVal
#> 1:         HL chiSq  4.622183  6 0.5930997
#> 2:        mHL     F  1.071882  7 0.3844230
#> 3:       OsRo     Z -0.501724 NA 0.6158617
#> 4: SstPgeq0.5     Z  1.348843 NA 0.1773873
#> 5:   SstPl0.5     Z  1.516578 NA 0.1293733
#> 6:    SstBoth chiSq  4.119387  2 0.1274931
#> 7: SllPgeq0.5 chiSq  1.579811  1 0.2087879
#> 8:   SllPl0.5 chiSq  2.311910  1 0.1283862
#> 9:    SllBoth chiSq  2.341198  2 0.3101811

The Hosmer Lemeshow, modified Hosmer Lemeshow and Oseo Rojek are all above $5 %$ values which are supportive of good fit of the model.

14.18 Presentation

The gtsummary package has a useful function tbld_regression() to produce a formatted table suitable for publication.

This is the table for adjusted log odds ratio:

tbl_regression(fatal_mv2)

Characteristic	log(OR)¹	95% CI¹	p-value
earliest Glasgow Coma Scale	-0.34	-0.45, -0.24
Ischaemic Stroke or Haemorrhagic
Ischaemic Stroke	—	—
Haemorrhagic	1.2	0.38, 2.1	0.004
age in years	0.02	0.00, 0.05	0.11
¹ OR = Odds Ratio, CI = Confidence Interval

And this is the table for adjusted odds ratio:

tbl_regression(fatal_mv2, exponentiate = TRUE)

Characteristic	OR¹	95% CI¹	p-value
earliest Glasgow Coma Scale	0.71	0.64, 0.79
Ischaemic Stroke or Haemorrhagic
Ischaemic Stroke	—	—
Haemorrhagic	3.40	1.46, 7.97	0.004
age in years	1.02	1.00, 1.05	0.11
¹ OR = Odds Ratio, CI = Confidence Interval

14.19 Resources

13 💻 Intermediate prep

15 💻 Binary LogReg exer
